Labels that apply to plane product labeling are sticker labels used by rolling machines, for example, sticker labels used in hardware, electronics, stationery, food, pharmaceuticals, cosmetics, and daily chemicals, as well as plastic bottles, glass bottles, and buckets in chemical factories.

Specific products include bread, Guiling jelly cover, ice cream cover, battery, flat-bottle shampoo, flat-bottle body wash, CD case, CD bag, square cotton swab, lighter, correction fluid, paint bucket, and carton.

● Machine materials:S304 stainless steel and anodized advanced aluminum alloy.

● Power for labeling:advanced stepping servo motor.

● Advanced photoelectric eye made by Japanese or German enterprises.

● Control:PLC and man machine interface.

● Adjustable labeling position:front，rear，up，or down.

● Inner diameter of paper roll 76mm；outer diameter o 360mm.

● Belt width of conveying machine：137mm（width can be adjusted according to customer requirements）.

● Conveying machine width：185mm.

● Label specifications:bottom paper width 20~130mm（width can be adjusted according to customer requirements）.

● Labeling precision ±1mm（except for errors of the products and labels）.

Labeling speed：0-25m/min

Power：400W，AC220V/50Hz or 110V/60Hz

Net weight of machine：100kg

Boxing weight：200kg

Machine dimensions: L1400mm×W800mm×H1400mm

Boxing dimensions: L1600mm×W1000mm×H1600mm
